Concept Pro

4 Channel 8MP Professional NVR

SKU: VUHDIP-4-3

  • Recorder Type

    NVR

  • Hard Drive Size

    Up to 12TB

  • Resolution

    8MP

  • Codec

    H.265, H.264, MJPEG

  • Audio & Alarm

    x2/x1 Alarm in/out

  • Display output

    Ultra high Definition

The VUHDIPL-4-2 model is a four channel network video recorder designed to satisfy most entry-level to professional requirements. It has four channels of PoE/PoE+ built-in, supports the latest H.265 video compression codec for greater storage and bandwidth savings, and provides real-time recording performance at up to 8-megapixel resolutions across all channels.

Dimensions: 260(W) × 262.6(D) × 44(H) mm, 1U

Other Key Features

  • NDAA Compliant
  • 4 PoE IP Camera Inputs
  • H.265 and H.264 Video Codec Support
  • Up to 12TB Internal Hard Disk
  • Arm/Disarm Switch to Configure Alarm Notification
  • Real-time 8MP Camera Video Recording (4K UHD)
  • 4K HDMI and VGA Display Output
  • Enhanced Password Security Rules
  • 2CH Alarm Input/1CH Alarm Output
  • 4 Channel
  • VBR+
  • H.265 Storage Compression
  • HDMI
  • VGA
  • Alarm in/out
  • USB
  • 4K Output
  • 4K Recording
  • ONVIF Compliant
  • Professional Remote Monitoring

Professional Remote Monitoring – Provides 24 hours remote monitoring for clients and is available on all Concept Pro recorders with Alarm Receiving Stations using Immix Cloud and Sentinel platforms.

  • Deep Learning Video Analytics

Deep Learning Video Analytics. this product supports the latest Deep Learning video analytics technology when compatible Concept Pro IP cameras are connected. Easily configure Deep Learning Motion Detection and advanced video analytics rules from the recorder user interface and begin reducing false alarms by up to 95% with the power of Deep Learning.

  • Enhanced Security

This product supports a suite of security – related features, including automatic password expiration, encryption and more settings designed to ensure authorised users are accessing the device.

Datasheet

  • Technical Datasheet 2022
    English
    Format PDF (2 MB)

    Format PDF (2 MB)

Specifications

Dimensions

All meaurements are in mm.

professional NVR dimensions
